90° Male Cord Connectors
90° Male Cord Connectors
| ALUMINUM 3/8” – 1” NPT | |||
|---|---|---|---|
|
NPT HUB SIZE
|
DIAMETER RANGE
|
FORM SIZE
|
CATALOG NUMBER
|
|
INCHES
|
|||
|
3/8”
|
.062 – .125
.125 – .187 .187 – .250 .250 – .312 .312 – .375 .375 – .437 |
F1
|
NCG12F1
NCG18F1 NCG25F1 NCG31F1 NCG37F1 NCG43F1* |
|
1/2”
|
.062 – .125
.125 – .187 .187 – .250 .250 – .375 .312 – .437 .375 – .500 .500 – .625 |
F2
|
NCG12F2
NCG18F2 NCG25F2 NCG37F2 NCG43F2 NCG50F2* NCG62F2* |
|
3/4”
|
.375 – .500
.500 – .625 .625 – .750 .750 – .875 |
F3
|
NCG50F3
NCG62F3 NCG75F3* NCG87F3* |
|
1”
|
.375 – .500
.500 – .625 .625 – .750 .750 – .875 .875 – 1.000 1.00 – 1.125 |
F4
|
NCG50F4
NCG62F4 NCG75F4 NCG87F4 NCG100F4* NCG112F4* |
|
ALUMINUM 1 1/4” – 2” NPT
|
|||
|---|---|---|---|
|
NPT HUB SIZE
|
DIAMETER RANGE
|
FORM SIZE
|
CATALOG NUMBER
|
|
INCHES
|
|||
|
1 1/4”
|
.750 – .875
.875 – 1.000 1.000 – 1.125 1.125 – 1.250 1.250 – 1.375 1.375 – 1.437 |
F5
|
NCG87F5
NCG100F5 NCG112F5 NCG125F5* NCG137F5 * NCG143F5 * |
|
1 1/2”
|
.750 – .875
.875 – 1.000 1.000 – 1.125 1.125 – 1.250 1.250 – 1.375 1.375 – 1.437 1.250 – 1.375 1.375 – 1.500 |
F6
|
NCG87F6
NCG100F6 NCG112F6 NCG125F6 NCG137F6 NCG143F6 NCG137F7 NCG150F7 |
|
2”
|
1.500 – 1.625
1.625 – 1.750 1.750 – 1.875 1.875 – 1.937 1.937 – 2.000 |
F7
|
NCG162F7
NCG175F7 NCG187F7 NCG193F7 NCG200F7* |
* Cable jacket may have to be stripped to pass through connector.
